►PDU Low-Voltage Cable


Product Applications
PDU applied to new energy cars outside Low-Medium Current Cable, cable range 2-4mm², the harness can be used with the multi-core or a separate shielded cable. We design for new energy vehicle wiring harness and we have taken an active part on developing all kinds of PDU in the low-voltage wire harness processing and manufacturing.
Under Development

Product Features

.Slide-type interlock and slide-type release
.Intuitive, no-press operation
.Six anti-missing and foolproof designs
.Connector and Plug waterproof IP67 rating
.Anti-finger touch, safe design with tool opening
.Two-stage interlocking design


Specification

Item Description
Electrical performance Rated Voltage 600V DC
Rated Current 25 A
Mechanical behavior Mating/unMating Cycling >500
Waterproof level IP67
IP69K
Electrical Protection IP2XB
Bolt M4
Material Thermoplastic Thermoplastic
Flammability rating UL94V-0

Download file

 Product Drawing : Plug Type / Jack Type
